Material: Our gage sticks are manufactured from various kiln-dried hard work. The material used is selected for color, strength and straightness. The size blank used depends on the type gage stick. One piece and sectional gage sticks are 21mm x 21mm. Folding gage sticks are 16mm x 21mm. Drum gage sticks are 16mm x 16mm. These dimensions may vary slightly without prior notice by us.

Printing: We print our gage sticks with chemical resistant ink in inches in 1/8" increments with each inch line numbered and in metric in 5mm increments with each centimeter line numbered.

Accuracy: Our calibrations have a maximum variation of 1/16" per 8' of calibration. Drum stick calibration are based on standard closed head steel drum where a drum on it's end is full at 32" level and drum on it's side is full at 22"level.

Protective Coating: All gage sticks are finished on the printed side(s) with three sprayed coats of clear semi-gloss catalyzed varnish material. The unprinted backside is finished with two coats of the same material. The side(s) adjacent to the printed side(s) are roll coated with a dull black urethane material. Compatible with E10, E85 and B6 to B20 fuels.

Bottom Tip Protection: The bottom tip of each type gage stick we make, with the exception of drum gage sticks, is shipped with an installed 5/8" diameter polypropylene tip protector.

Items shown in blue can be shipped UPS

Gage Stick Discount: Combine quantities for best price

Example: 50 of two different units will both be priced at 100 units
12 is minimum order for combination printed and two side reversed printed per part number ordered

Terms: Net 30 days

Freight: All FOB Pinson, Alabama 35126
We will prepay and add or ship collect via carrier of your choice
